Deep Drawing

Deep drawing is a sheet metal forming process in which a sheet metal blank is radially drawn into a forming die by the mechanical action of a punch.It is thus a shape transformation process with material retention. Metalli’s deep drawing process consists a wide variety of material scopes and designs. Our custom deep drawing services offer a cost-effective and on-demand solution for your manufacturing requirements.

Metalli’s deep drawing capabilities

● Product dimension up to Length*Width 1200*1000 mm

● Depth or height up to 500 mm

● Wall thickness up to 6 mm

● Tolerance ±0.2 mm or less

● Common shapes covering round, cone, square, rectangle, and irregular

● Tools design available in house

● 10 hydraulic press machines from 100 tons to 1000 tons
